Module Type:Ethernet Network TCP/IP Module
Product ID:140NOE77111
Brand:SCHNEIDER
Compatibility:Modicon Quantum PLC
Communication Protocol:Ethernet TCP/IP 10/100BaseTx
Power Supply:Via the power supply of the rack
Current Consumption:750 mA 5 V DC
Weight:0.345 kg
Features:[“Modbus Messaging”,”I/O Scanning”,”Global Data”,”Faulty Device Replacement (FDR)”,”Bandwidth Management”,”SNMP Agent”,”Diagnostic Web Server (Rack Viewer, Data Editor, Alarm Viewer, Graphic Editor, SOAP/WSDL Server, Customized Web Pages)”]
The SCHNEIDER 140NOE77111 is a versatile and robust FactoryCast module specifically engineered for use with Modicon Quantum PLC systems. Designed for seamless integration within modern industrial networks, it offers advanced Ethernet connectivity through its support of TCP/IP protocol at speeds up to 10/100BaseTx. Key features include Modbus messaging, which ensures efficient communication between devices, and I/O scanning, which provides real-time monitoring of input/output operations.
The module’s global data handling capability allows for consistent and reliable data exchange across multiple nodes, enhancing overall system performance. Additionally, it includes Faulty Device Replacement (FDR) functionality, which helps to quickly identify and replace malfunctioning devices without interrupting production processes. This feature significantly improves operational continuity and reduces downtime.
Bandwidth management tools allow users to optimize network traffic, ensuring smooth operation even under heavy load conditions. The module is equipped with an SNMP agent and a comprehensive diagnostic web server, offering access to rack viewer, data editor, alarm viewer, graphic editor, and SOAP/WSDL server functionalities via a user-friendly interface. These tools enable remote diagnostics and configuration, facilitating proactive maintenance and troubleshooting.
Conformal coating on the module protects it from harsh environmental conditions, ensuring reliable operation in challenging industrial settings. The inclusion of Web Designer configuration software (not Full Edition) provides users with essential configuration tools, allowing for easy setup and customization of the module’s settings.
