NI PXIE-5645R Real-Time Multifunction I/O Module

Module Type:Real-Time Multifunction I/O Module

Order Number:PXIE-5645R

Custom Processing:Yes

Item No.:PXIE-5645R

Brand:NI

Series:PXIE-5645R

Compatibility:Designed for PXI Express Systems

Analog Input Channels:Up to 4 channels

Resolution:16-bit

Sampling Rate:Up to 1 MS/s per channel

Input Range:-10V to +10V

Triggering:Software and hardware triggering options

Timing:Onboard clock with programmable timebase

Operating System:Windows, Linux, RTOS

Power Supply:3.3V, 5V, ±12V DC

    The NI PXIE-5645R is an advanced real-time FPGA module, perfectly suited for demanding industrial control systems. This module integrates a dual-core ARM Cortex-A9 processor with a high-speed clock rate, ensuring seamless operation in critical applications. With 1 GB of DDR3 RAM and 16 MB of QSPI Flash, it provides ample memory for complex operations and data storage. It features up to 8 analog input channels and 2 analog output channels, each capable of sampling at rates up to 100 MS/s with a resolution of 16 bits. Additionally, it offers 100 lines of digital I/O, allowing for versatile interfacing with various sensors and actuators. Designed with robustness and reliability in mind, the PXIE-5645R is built to withstand harsh industrial environments. Its compact form factor makes it easy to integrate into existing systems without compromising on performance. Ideal for applications requiring real-time data processing and rapid prototyping, the NI PXIE-5645R sets new standards in industrial automation and testing.
