Manufacturer:National Instruments
Model Number:NI NI-9505
Module Type:Data Acquisition Module
Channels:32 Channels
Sampling Rate:1 MS/s
Resolution:16-bit
Input Range:+/- 10V
Operating Temperature Range:-40°C to +85°C
Power Supply:5V DC
Dimensions:165mm x 100mm x 25mm
Weight:0.3kg
The NI NI-9505 Control Module is a high-performance digital input module designed for industrial automation systems. It offers 32 channels with a wide voltage range of 0 to 5V DC, ensuring compatibility with a variety of sensors and devices.
This module supports a sampling rate of up to 100 kS/s per channel, making it ideal for fast and accurate data acquisition in demanding industrial environments. The channel-to-channel isolation feature enhances system reliability by preventing signal interference.
Designed for harsh industrial conditions, the NI NI-9505 operates within a broad temperature range from -40°C to 85°C. Its compact dimensions (90 mm x 100 mm x 25 mm) and lightweight design (150 grams) make it easy to integrate into existing control systems without compromising on performance.
The module requires only 5V DC power, simplifying integration with standard industrial power supplies. It is compatible with National Instruments’ LabVIEW software, allowing for seamless configuration and monitoring of your control system.
With its robust construction and versatile capabilities, the NI NI-9505 Control Module is an essential component for any industrial automation project. Whether you are modernizing an existing facility or building a new one, this module delivers the reliability and precision you need.
