Allen-Bradley Kinetix 6000 Series 2094-AM02-S Axis Module – Advanced Motion Control Solution

Module Type:Axis Module

Series:Kinetix 6000

Efficiency:0.98

Continuous Current (rms):10.6 A

Continuous Current (0-peak):15.0 A

PWM Frequency:4 kHz

Bandwidth Velocity Loop:500 Hz

Internal Shunt Continuous Power:N/A

Internal Shunt Peak Power:N/A

Nominal Input Voltage:325 VDC

Shunt On:N/A

    Integrating advanced technology with robust engineering, the Allen-Bradley AB 2094-AM02-S Kinetix Multi-Axis Servo Drive Module is designed for seamless integration into complex industrial machinery, ensuring optimal performance under various operational conditions.

    Featuring a 4 kHz PWM frequency and a velocity loop bandwidth of 500 Hz, this module ensures precise control over motors, delivering exceptional speed and position accuracy.

    With a continuous current capacity of 10.6 A and a peak current of 15.0 A, the module is capable of handling heavy-duty tasks while maintaining efficiency at 0.98.

    Engineered for durability and reliability, the internal shunt of the module supports both continuous and peak power requirements, making it suitable for applications where power management is critical.

    Equipped with a nominal input voltage of 325 Volts DC, the module ensures compatibility with a wide range of power sources commonly found in industrial settings, further enhancing its versatility and applicability.
