ABB AO810 3BSE008522R1 Analog Output Module

Model:3BSE008522R1

Module Type:Analog Output

Brand:ABB

Operating Voltage:24V DC

Load Current:Up to 1A per channel

Number of Channels:8

Accuracy:+/- 0.5% of full scale

Response Time:Less than 5ms

Communication Interface:Built-in RS-485

Environmental Conditions:Operating Temperature: -25°C to +60°C, Storage Temperature: -40°C to +85°C

    The ABB AO810 3BSE008522R1 Analog Output Module is a cornerstone of precision control systems, offering unparalleled accuracy in signal transmission. It seamlessly integrates with a variety of industrial automation systems, ensuring reliable performance across diverse operational environments.

    Crafted with a compact DIN rail mountable design, this module ensures efficient space utilization and ease of installation, making it a practical choice for retrofitting or new installations. Its aluminum alloy construction provides a sturdy base, capable of enduring the rigors of industrial conditions without compromising on its performance capabilities.

    Featuring compatibility with MODBUS RTU protocols, this module facilitates seamless communication between different control systems, enhancing system integration and data exchange. Whether it’s controlling machinery, monitoring processes, or adjusting parameters in real-time, the ABB AO810 delivers consistent and dependable analog outputs, essential for achieving optimal process efficiency.

    With an operating voltage range up to 24V DC and a temperature tolerance from -25°C to +60°C, this module is engineered to withstand challenging industrial environments. Its single analog output, either 0-10V or 4-20mA, ensures precise control over actuators, valves, and other devices requiring analog feedback.

    Designed with safety in mind, the IP20 enclosure rating ensures basic protection against dust and splashes, safeguarding the internal components from potential damage. This module is a testament to ABB‘s commitment to quality and reliability, backed by comprehensive technical support and extensive field experience in industrial automation.
