Brand:Allen-Bradley
Model:1783-MS10T
Module Type:Modular System Controller
Input Voltage:24 VDC
Output Voltage:24 VDC
Operating Temperature Range:-40°C to 70°C
Humidity Range:5% to 95% (non-condensing)
Communication Interfaces:RS232, RS485, Ethernet
Memory Capacity:1 MB Flash Memory, 512 KB RAM
Programmable Languages:Structured Text, Ladder Logic, Function Block Diagram
Dimensions:Width: 175mm, Height: 85mm, Depth: 135mm
Weight:Approximately 1.2kg
The Rockwell Automation A-B 1783-MS10T Expansion Module is designed to complement the MicroLogix 1000 series controllers by providing additional digital I/O channels, making it an ideal solution for small-scale automation systems.
This expansion module features 8 digital inputs and 6 digital outputs, allowing users to easily expand their control system capabilities without the need for additional hardware.
Built for reliability and durability, the A-B 1783-MS10T operates within a wide temperature range from -40°C to 70°C and maintains performance under high humidity conditions up to 95%, ensuring stable operation in harsh environments.
The compact design of the module measures approximately 70mm x 80mm x 30mm and weighs around 0.1kg, making it easy to integrate into existing systems or deploy in space-constrained areas.
With its robust construction and versatile connectivity options, the A-B 1783-MS10T is suitable for various applications, including factory automation, machinery control, and process control systems.
